Sloping concrete paving machine
EQUIPMENT SPECIFICATIONS
Model | SC7000 |
Maximum length of the sloping roof to be constructed | 7.5m |
Horizontal concrete conveyor | 2.2 kw |
Material screw | Ø 350mm x dài 7,5 m |
Screw conveyor motor power | 5.5 kw |
Conveyor motor power | 2.2 kw |
Motor power for leg lifting | 0.75kw-4p |
Receiving concrete from the tanker truck, discharging concrete into the screw conveyor; Power: 2.2 kW; Capacity: 60 m³/h
PRELIMINARY CONCRETE COMPACTION MACHINE FOR SLOPE CONSTRUCTION 1:1
- Movement by 2 x 2.2 kW electric motors on rails, 4 adjustable height legs controlled by motors.
- Material screw conveyor: Screw conveyor diameter: 350 mm, modular design. Spreading surface length: 4-7.5 m depending on model. Motor power: 5.5 kW, 2-way control.
- Concrete vibrator: 1.5 kW power. Vibrator spacing: 0.8-1 m, fixed to the machine frame via spring shock absorbers.
- Vibrating screed mounted on the shock absorber system: Vibrating motor power: 1.5 kW, spacing: 2 m/scr.
- The machine frame system is a trough-shaped unit with an open mouth and bottom, manufactured in a modular fashion.
